ROMAX factory is one of the biggest and up-to-date producers of equipment for elevators and other units for storage and processing of grain. Due to its capacity and automation ROMAX holds a dominant position in Russian market. It is also one of the most powerful factories in Europe.

We have:

production space - 24 800 m2;

warehouse - 7 800 m2;

more stuff – more then 200 persons.

ROMAX factory produces and puts up for sale equipment for grain processing complexes such as elevators, compound feed mills, seed trains etc.

ALFA MGC

ALFA MGC (Mobile Grain Complex) is a mobile grain complex with capacity from 80 till 150 t/h. Grain cleaning machine ALFA MGC is very flexible and can therefore be used for different purposes. First of all ALFA MGS feeds the grain from the field into feed hopper by using an infeed conveyor. Then it cleans the grain from big and light particles and after that discharges the cleaned grain into auto transport facilities.

	Specifications:
Denomination	ALFA  MGC 100	ALFA MGC 150	Unit
Type	mobile	mobile	-
Capacity	80	150	t/h
Machine weight	23 500	2 500	kg
Power	16,05	24,75	kW



ALFA

Grain cleaning machine ALFA with capacity 50-400 t/h is used for plecleaning of specked cereals, grain, grain legume, corn, sorgo and sunflower seed. It is suitable for work as a part of immobile in-line system and used in different climatic zones



Specifications:

Denomination	ALFA -50	ALFA -100	ALFA -150	ALFA -200	ALFA -300	ALFA -400	Unit
Type	immobile	immobile	immobile	immobile	immobile	immobile	-
Capacity	50	100	150	200	300	400	t/h
Total weight of the machine	500	980	1 180	1 250	1 350	1 350	kg
Power	3,55	4,55	4,75	6,6	9	9	kW



BETA is an all-purpose cleaning machine for grain, legumes, oilseeds.
•     The vibrating screens are made of galvanized steel with good quality and durability (suitable for food).
•     Screens are cleaned by rubber balls.
•     Adjustable feeding speed.
•     Adjustable gate (industrial and fine cleaning).



Specifications:

Denomination	BETA 60	BETA 120	Unit
Capacity (Industrial)
Industrial cleaning	50	100	t/h
Capacity (all-purpose)
Industrial cleaning	50	100	t/h
Fine cleaning	6	12	t/h
Total screen area	6	12	m3
Machine weight	1 900	3 000	kg
Power	3	5,5	kW

GAMMA

Specifications:

Denomination	GAMMA 100	GAMMA 200	Unit
Capacity	up to 100	до 200	t/h
Exhaust air	3 000 - 6 000	3 000 - 7 500	m3/h
Power	3,55	4,55	kW
Rotation frequency	700 - 900	700 - 900	rpm
Dimensions l/W/H	2 476/930/1 846	2 476/1 120/2 134	mm

GAMMA is an aspiration unit for separation of glume and impurities with different aerodynamic quality. GAMMA is a good supplement for all screen machines.

GAMMA provides clear separation of grain and impurities. Adjustable air flow also provides separation of feeble grain
and weed seeds.

EQUIPMENT FOR ELEVATORS

Cone silo

Specifications of silo

ROMAX produces high impact cone silos with cone tilt angle 450, 600 and 660.  These silos are suitable for
processing of 23 m3 - 2643 m3 of material.

Roof, cylinder and silo supports are made of strong structural steel.

Steel: S350 GD

Tensile strength: 350 N/mm2

Galvanisation up to 450 g/m2

Bolts 8.8

Wind pressure for ROMAX silos is up to 73 kg/m2 (wind speed is up to 107 km/h). Silo with grain can carry the load with wing speed up to 145 km/hour or
40 m/s).

The  production  is  totally  automatically  controlled. Every year we handle with 25 000 t of steel. It means that we produce equipment with total storage capacity of 2 500 000 t.

Standard list of equipment for cone silo is: roof ladder with hand guard, maintenance hatch on cylinder and roof of the silo, fully equipped roof, on top ladder with guards and platform for the rest under the maintenance hatch, ladder with guard into maintenance hatch for the stuff, molding between cylinder and roof of the silo that protects silo from snow and water, bin level controller (upper and lower level).

On request:

•    Air dust system

•    Heat flow measurement system

•    Conveyor gallery 1 400 and 2 100 (we can provide enclosed conveyor gallery suitable for belt conveyor installation)

•    Stand masts for conveyor gallery with rest upon silo or upon concrete bottom of the silo

•    Valves (manual or electrically operated).

•    Ladder of the silo can be equipped with additional platforms for staff relax



Flat bottom silo

Specifications of silo
ROMAX produces high impact flat bottom silos for longtime storage of 414 m3 - 24 458 m3   of material.

Roof, cylinder and silo supports are made of strong structural steel grades.

Roof, cylinder and silo supports are made of strong structural steel.

Steel: S350 GD

Tensile strength: 350 N/mm2

Galvanisation up to 450 g/m2

Bolts 8.8

Wind pressure for ROMAX silos is up to 73 kg/m2 (wind speed is up to 107 km/h). Silo with grain can carry the load with wing speed up to 145 km/hour or 40 m/s).

The production is totally automatically controlled. Every year we handle with 25 000 t of steel. It means that we produce
equipment with total storage capacity of 2 500 000 t.

Standard list of equipment for cone silo is: roof ladder with hand guard, maintenance hatch on cylinder and roof of the silo, fully equipped roof, on top ladder with guards and platform for the rest under the maintenance hatch, ladder with guard into maintenance hatch for the stuff, molding between cylinder and roof of the silo that protects silo from snow and water, bin level controller (upper and lower level), floor-to-ceiling ladder inside the silo for the stuff.

On request:

•       Air dust system
•       Heat flow measurement system
•       Bin sweeper

•       Conveyor gallery 1 400 and 2 100 (we can provide enclosed conveyor gallery suitable for belt conveyor installation)
•       Stand masts for conveyor gallery with rest upon silo or upon concrete bottom of the silo
•       Valves (manual or electrically operated).

METALWARE

Receiving group

Receiving group of ROMAX enables   fail-safe equipment functionality in different terms and conditions of use.

Receiving group consists of raw material inlet hopper out of auto transport facilities.  You can use different types of auto transport: side-dump truck, end- dump truck and drop-side truck.

We can also provide you with receiving group out of railroad transport, chain conveyor or scraper chain conveyor.

Receiving  group  is  equipped  with  truck  tipper strong grating floor, designed for passage of vehicles and prevention of intrusion of foreign bodies inside the construction, conveyors capacity alignment system.

Specifications::

-       Volume: 30 – 150 m3

-       Length – 7 000 mm – 40 000 mm

-       Capacity of unloading – 10 – 500 t/h

Elevator tower

Supporting metalware is made for power-drive station service. All this equipment is correspond with industrial safety and fire safety standards. Metalware has bolted- on connection and is made of zinc-plated profiled metal which is very strong. There are inclined ladder with guards and platforms for the rest inside the tower. There are different types of towers for bucket elevators where you can place up to 8 machines.

Additional platforms and reinforcement of the gallery are optional.

Here are the advantages of using elevator towers of
ROMAX:

-       Fast structural construction

(2-4 days for the construction up to 30 m height)

-       Safety implementation

-       Design aesthetics

-       Competitive price



Dimensions:  3 000 mm x 3 300 mm

4 200 mm x 3 300 mm

4 200 mm x 3 700 mm

5 200 mm x 4 200 mm

6 000 mm x 4 200 mm

Height up to 65 000 mm

Metalware for grain cleaning equipment

Shelter, farms, towers

ROMAX produces metalware in accordance with the special features of grain cleaning machines, such as terms and conditions of use and capacity.

Metalware has bolted-on connection and is made
of zinc-plated profiled metal which is very strong.

ROMAX LTD works out and produces shelter, farms, towers in accordance with requirements of the clients.

ROMAX can produce towers for warehouses, plants, grain storages in accordance to the customs design



Grain drying equipment

Grain drying machines of ROMAX are suitable for drying all types of seeds: grain, corn, grain legumes and oil cropper.

A great range of models can supply the demand of every client. We produce the drying machines with the following specifications:
-       Capacity 5 – 200 t/h

-       Different  types  of  cleanup  systems  for  the spent air

-       Heat-exchange units operated on fuel gas or fuel-oil burners.

Grain drying machines of ROMAX can be used both in small farms and in huge Manufactures which are deal with plant products. The construction of these machines provides economic use of fuel and high quality of equipment when handle the material and grain.

ROMAX Ltd is a well-established factory. Its equipment is used by the companies situated on the huge territory from Russian Far East till the countries of Eastern Europe.

Denomination                                   Unit		Type	5	6	7	8	9	10	11	12	13	14	15	16	17	18
Heat rate (Qk)of the		GM	1000	1150	1300	1500
burner without heat exchange unit	kW	GL	1300	1550	1850	2150	2500	2900	3300	3700
		GXL	2000	2400	2800	3200	3600	4000	4400	4800	5200	5600	6000	6400	6800	7200
Capacity of the constantly used drying machine ROMAX.		GM	13,0	15,0	17,5	20,0
Wheat 19-15%, temperature - +15 C, air humidity 70%, heat	t/h	GL	18,0	21,5	25,0	29,0	33,5	39,0	45,0	50,0
temperature +95C		GXL	27,0	32,5	37,0	43,5	48,5	55,0	60,0	65,0	70,0	75,0	80,0	85,0	90,0	95,0
Capacity of the constantly used drying machine ROMAX. Corn		GM	4,3	5,0	5,5	6,6
30-15%, temperature +10 C, air humidity 70%, heat temperature	t/h	GL	5,9	7,1	8,0	9,6	10,8	12,9	14,9	16,2
+110C		GXL	8,9	10,7	12,0	14,4	15,8	18,2	19,8	21,3	23,1	24,6	26,4	28,1	29,5	31,4
Capacity of the constantly used drying machine ROMAX. Rape		GM	7,2	8,3	9,3	11,0
13-7%, temperature +15 C, air humidity 70%, heat temperature	t/h	GL	9,0	10,8	12,2	14,5	16,5	19,5	22,5	24,7
+80C		GXL	10,8	13,0	14,6	17,4	19,2	22,0	24,0	25,8	28,0	29,7	32,0	34,0	35,7	38,0
Capacity of the constantly used drying machine ROMAX.		GM	2,3	2,7	2,9	3,6
Sunflower seed 13-7%, temperature +15 C, air humidity 70%,	t/h	GL	4,5	5,4	6,0	7,3	8,1	9,8	11,3	12,2
heat temperature +80C		GXL	7,3	8,8	9,8	11,7	12,9	14,9	16,2	17,4	18,9	20,1	21,6	23,0	24,1	25,7

Bucket elevators

Bucket elevators of ROMAX are suitable for the vertical conveyance of granular material. The capacity is 5 – 2 500 t/h. The elevators are made for industrial needs and it means that they are robust and long- live. All the elevators are made of   top-level spare parts. Filling hopper, upper head cover and discharge chute are equipped with a polymeric plate. Thus the operating life becomes longer and the material isn’t damaged during the conveyance.

All the elevators are equipped with buckets by STIF (France). The construction of the buckets provides the increase in nominal capacity up to 10-15%.

High-impact belt can resist a load from 400 N/mm till 1 600 N/mm.

Specifications:

Denomination	Unit	E80	E130	E180	E280	E370	E450	E740
Capacity	t/h	5-15	20-40	40-80	80-160	160-300	230-340	340-500
Plate thickness:
Head panel	mm	3	3	4	5	5	6	8
Head and boot	mm	2-3	2-3	2-3	3-4	3-4	4-5	5
Column	mm	1,5	1,5	1,5	1,5	2	2,0	2
Buckets	Type	S130	S130	S180	S280	S370	S450	S740
Buckets per meter	Pcs.	12	12	10,5	9	7	7	7
Belt width	mm	125	150	200	300	400	500	800

Chain conveyors

Chain conveyors of ROMAX are suitable for the horizontal conveyance of granular material (angle of slop is no more than 70). The capacity is 5 – 2 500 t/h. The elevators are made for industrial needs and it means that they are robust and long-live.

Power drive   station with axle gear moor has an enhanced service factor index. It means that the conveyor is fail-safe in different conditions of use.

The bottom of the conveyor is equipped with a polymeric plate which thickness is 10 mm. It elongates the operating life of chain conveyor and minimizes the damages of the material during the conveyance.

The basic completing units of the machine: speed sensor, chain interruption sensor, level limit switch, filling and discharge.

Optional: flow-regulating valve, which is used for supplying the materials in 2 and more directions.

Specifications:

Type	K 40	K 60	K 100	K 150	K 200	K 300
Capacity  t/h	25-50	до 60	80-120	150-175	200-250	300-350
Thickness of panels cover / side / bottom mm	1,5/2/1,5	1,5/2/1,5	1,5/2/2	1,5/2,5/2	2/2,5/2,5	2/2,5/2,5
Weight 1 meter empty / full kg/m	40/65	45/83	59/123	75/179	98/218	150/300
Type DIN8165	35 x 5	35 x 5	40 x 6	45 x 6	50 x 8	50 x 8
Chain pitch/teeth mm/pc	100/7	100/8	125/8	125/10	160/9	160/10
Ø shaft mm	230,5	261,3	326,6	404,5	467,8	517,8

Scraper conveyors

Scraper conveyors ROMAX are designed for horizontal and inclined (with lifting up to  30°) displacement of bulk materials.

The scraper conveyors ROMAX, producing from 5 to 1,500 m3/h, are designed and manufactured in industrial design.

Reliable equipment and simple design solutions guarantee reliability and durability in operation.

The  equipment  is  equipped  with:  a  speed and chain failure monitoring sensor, a backup dataset, a backfill, an excavation.

If necessary, the units are equipped with valves.

Specifications:

Type	K 40	K 60	K 100	K 150
Capacity t/h Chain speed = 0.5 m/s	25-50	до 60	80-120	150-175
Moisture = 18%
Thickness of panels cover / side / bottom mm	1,5/2/1,5	1,5/2/1,5	1,5/2/2	1,5/2,5/2
Weight 1 meter empty / full kg/m	40/65	45/83	59/123	75/179
Type DIN 8165	35 x 5	35 x 5	40 x 6	45 x 6
Chain pitch/teeth mm/pcs	100/7	100/8	125/8	125/10
Ø shaft mm	230,5	261,3	326,6	404,5

Belt conveyors

ROMAX  belt  conveyors  (type  B)  are  made  for horizontal conveying of bulk products.

It can be used in agricultural and chemical industry, while handling with mineral commodities.

Capacity - 60 - 1 500 m3/h. Conveyors are made for industrial purpose.

Drive  stations with  an  axial  motor-reducer have an increased service factor, thus it can be used in different conditions.

Specifications:



Type                                                       B 400              B 500              B 600              B 750              B 800           B 1000         B 1 200



Capacity t/h                                                                                                     45                         80                     80-120                 150-175                200-250              300-350             300-350



Belt width mm                                                                                                400                       500                       600                       700                       800                    1000                 1200

Outlet mm	Ø 200	Ø 200	Ø 250	Ø 250	Ø 300	Ø 300	Ø 300
Drum diameter mm	Ø 200	Ø 215	Ø 215	Ø 215	Ø 400	Ø 500	Ø 600
Supporting roller length mm	210	250	300	350	2х250 +	2х250 +	2х250 +
					1х350	1х450	1х550
Return roller length mm	500	600	700	800	900	1100	1300
